High-Precision Stereo 2-Way/Mono 3-Way Crossover with Subwoofer Output
PRODUCT DETAILS
- Professional stereo 2-way/mono 3-way crossover
- Internal switch-mode power supply for worldwide, 100€“240V operation
- State-of-the-art Linkwitz-Riley filters with 24 dB/octave
- Additional subwoofer output with independent Frequency control
- Absolutely flat summed amplitude response, zero phase difference
- Individual output Gain controls for all bands
- Individual output Mute switches for easy band adjustment
- Individual Phase reverse switches for instant phase correction
- Switchable 25 Hz Low cut filter on each input for low-frequency driver protection
- Servo-balanced and gold-plated XLR connectors for all inputs and outputs
- Ultra-high precision potentiometers for ultimate accuracy and repeatability
- Illuminated switches for secure operation in dark stage environments
- High-quality components and exceptionally rugged construction ensure long life
- Modes:2-way Stereo, 3-way Mono
- Filter Types:Linkwitz-Riley
- Filters:24 dB/Octave
- Crossover Frequencies - Stereo:Low, High
- Crossover Frequencies - Mono:Low, Mid, High
- Inputs:2 x XLR
- Outputs:2 x XLR (low/mid), 2 x XLR (high), 1 x XLR (sub out)
- Rack Spaces:1U
- Height:1.7"
- Depth:5.8"
- Width:19"
- Weight:3.5 lbs.
- Manufacturer Part Number:cx2310v2
